QNAP 12-Bay 10GbE Rackmount NAS
CPU : Annapurna Labs Alpine AL-324 Quad-Core 1.7 GHz
Memory : 4 GB DDR4
LAN : 2 x 2.5 Gigabit + 2 x 10GbE SFP+
PCIe Slot : 1 x PCIe Gen 2 x2
Redundant Power Supply (2 x 250W)
With 10GbE SFP+ and 2.5GbE network ports, the TS-1232PXU-RP delivers high network bandwidth to streamline team collaboration and file access. A PCIe Gen 2 ×2 slot allows for installing a QNAP expansion card to add network connectivity, SSD caching capabilities, or wireless connectivity. The TS-1232PXU-RP supports file backup and synchronization, secure snapshot protection, and Google G Suite and Microsoft 365 enterprise account backup services, while providing instant recovery whenever needed.
Hardware Specification :
QNAP TS-1232PXU-RP-4G 12-Bay Rackmount NAS with Redundant Power Supply
| CPU |
Annapurna Labs Alpine AL-324 ARM Cortex-A57 Quad-Core 1.7 GHz processor, 64-bit ARM |
| Floating Point Unit |
Yes |
| Encryption Engine |
Yes |
| System Memory | 4 GB UDIMM DDR4 (1 x 4 GB) / Max. 16 GB (1 x 16GB) |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Hard Disk Drive |
12 x 3.5-inch SATA 6 Gbps bays The system is shipped without Hard Disk |
| Drive Compatibility |
• 3.5-inch SATA 6Gb/s HDD • 2.5-inch SATA 6Gb/s HDD • 2.5-inch SATA 6Gb/s SSD |
| SSD Cache Acceleration |
Yes Optional: SSDs on QM2 PCIe expansion card |
| LAN Port |
• 2 x 10GbE SFP+ 10 Gigabit Ethernet Port • 2 x 2.5 Gigabit Ethernet Port |
| PCIe Slot |
Slot 1: PCIe Gen 2 x2 |
| USB Port |
4 x USB 3.1 Gen 1 Type-A |
| Form Factor | 2U Rackmount |
| Power Supply | 2x ATX 250W (Redundant Power Supply) |
| Dimension | 89 x 482 x 534 mm |
| Weight | Net: 11.34 kg |
QNAP NAS is shipped without Hard Disk / 3 years warranty
Rack Rail Kit is option to buy
