QNAP TS-464-4G 4-Bay NAS with 2.5GbE / M.2 Slots
QNAP 4-Bay NAS
CPU : Intel Celeron N5105/N5095 Processor
Memory : 4GB DDR4
M.2 SSD Slot : 2
2.5 Gigabit Ports : 2
PCIe Slot : 1
USB 3.2 Gen 1 port : 2
USB 3.2 Gen 2 Port : 2
QNAP 4-Bay NAS
CPU : Intel Celeron N5105/N5095 Processor
Memory : 4GB DDR4
M.2 SSD Slot : 2
2.5 Gigabit Ports : 2
PCIe Slot : 1
USB 3.2 Gen 1 port : 2
USB 3.2 Gen 2 Port : 2
Powered by an Intel Celeron N5105/N5095, quad-core processor (burst up to 2.9GHz), the TS-464 features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-464 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards.
The TS-464 comes with 4GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS
The system is shipped without HDD
Hardware Specification :
QNAP TS-464-4G 4-Bay NAS
CPU |
Intel Celeron N5105/N5095 4-core/4-thread processor, burst up to 2.9 GHz |
System memory |
4 GB SO-DIMM DDR4 (1 x 4 GB) |
Flash Memory | 4GB (Dual boot OS protection) |
M.2 SSD Slot |
The M.2 SSD is not included as standard. |
Hard Disk Drive |
Hot-swappable 4 x 3.5-inch SATA 6 Gbps bays The system is shipped without Hard Disk |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
LAN Port |
2 x 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
PCIe Slot | Slot 1: PCIe Gen 3 x2 |
USB |
2 x USB 2.0 port 2 x USB 3.2 Gen 2 (10Gbps) Port USB 3.2 Gen 2 (10Gbps) Port |
HDMI Output | 1 x HDMI 2.0 |
LED Indicators | Power/Status, LAN, USB, HDD1-4 |
Buttons |
Power, USB copy, Reset |
Form Factor | Tower |
Dimensions | 168 x 170 x 226 mm |
Weight | 2.26 kg |
