QNAP TS-664-4G 6-Bay NAS with 2.5GbE / M.2 Slots

Display all pictures

Print
View full size

QNAP 6-Bay NAS

CPU : Intel Celeron N5105/N5095 Processor

Memory : 4GB DDR4

M.2 SSD Slot : 2

2.5 Gigabit Ports : 2

PCIe Slot : 1

USB 3.2 Gen 1 port : 2

USB 3.2 Gen 2 Port : 2

More details

More info

QNAP TS-664-4G 6-Bay NAS

Powered by an Intel Celeron N5105/N5095, quad-core processor (burst up to 2.9GHz), the TS-664 features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-664 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards.

The TS-664 comes with 4GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS

The system is shipped without HDD

Hardware Specification :

QNAP TS-664-4G 6-Bay NAS

CPU	Intel Celeron N5105/N5095 4-core/4-thread processor, burst up to 2.9 GHz CPU Architecture 64-bit x86 Graphic Processors Intel UHD Graphics Floating Point Unit ✓ Encryption Engine ✓(AES-NI) Hardware-accelerated Transcoding ✓
System memory	4 GB SO-DIMM DDR4 (1 x 4 GB) Maximum Memory 16 GB (2 x 8GB) Memory Slo 2 x SO-DIMM DDR4
Flash Memory	4GB (Dual boot OS protection)
M.2 SSD Slot	The M.2 SSD is not included as standard.
Hard Disk Drive	Hot-swappable 6 x 3.5-inch SATA 6 Gbps bays The system is shipped without Hard Disk
Drive Compatibility	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
LAN Port	2 x 2.5 Gigabit Ethernet Port (2.5G/1G/100M)
PCIe Slot	Slot 1: PCIe Gen 3 x2
USB	2 x USB 2.0 port 2 x USB 3.2 Gen 2 (10Gbps) Port USB 3.2 Gen 2 (10Gbps) Port
HDMI Output	1 x HDMI 2.0
LED Indicators	Power/Status, LAN, USB, HDD1-4
Buttons	Power, USB copy, Reset
Form Factor	Tower
Dimensions	168 x 235 x 226 mm
Weight	2.9 kg
