Synology RackStation ​RS3621xs+ 12-Bay Highly Scalable Rackmount NAS

Synology 12-Bay Rackmount NAS

CPU : Intel Xeon D-1541 8-core 2.1 GHz (64-bit)

Memory : 8 GB DDR4 ECC (Up to 64 GB)

Drive Bay : 12 (Up to 36)

LAN Port : 2 x RJ-45 10GbE

LAN Port : 4 x RJ-45 1GbE

USB Port : 2 x USB 3.2 Gen 1

PCIe Expansion : 2 x Gen3 x8 slot

Redundant Power Supply

More details

Synology RackStation ​RS3621xs+
12-Bay Rackmount NAS



High-performance enterprise storage built for data accuracy and security.



The 12-bay RS3621xs+ is capable of delivering over 238K 4K random read IOPS and 5,819 MB/s sequential read throughput - a true enterprise powerhouse. With full power supply redundancy, an 8-core processor, ECC memory, advanced snapshot technology, and file self-healing, the RS3621xs+ provides a reliable foundation to any data-driven business.



Hardware Specification :

Synology RackStation RS3621xs+ 12-Bay Rackmount NAS

Synology NAS is shipped without hard drive & Rack Rail Kit

CPU

Intel Xeon D-1541 8-core 2.1 (base) / 2.7 (turbo) GHz

Hardware Encryption Engine (AES-NI)

System Memory

8 GB DDR4 ECC UDIMM (1 x 8GB)

Memory Expandable up to 64 GB (16 GB x 4)

Drive Bays

12 Drive Bays Hot Swappable

Maximum Drive Bays with 36 Expansion Units

Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

(hard drives not included)

Supported RAID Type

RAID F1 / Basic / JBOD /

RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10

External Ports

RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)

RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)

USB 3.2 Gen 1 Port : 2

Expansion Port : 2

PCIe Expansion

2 x Gen3 x8 slots (x8 link)

Maximum IP cam

90 (including 2 Free License)

Virtualization

VMware vSphere with VAAI

Windows Server 2016

Windows Server 2019

Citrix Ready

OpenStack

Power Supply Unit  2 X 500W
Size 88 x 482 x 724 mm
Weight  14.5 kg
Warranty 5 year
