Synology FlashStation FS6400 24-Bay 2.5" Rackmount NAS

Synology 24-Bay Rackmount NAS

CPU : Intel Xeon Silver 4110 x 2

Memory : 32 GB DDR4 ECC (Up to 512GB)

Drive Bay : 24 (Up to 72)

RJ-45 1GbE LAN Port : 2

RJ-45 1GbE LAN Port : 2

USB USB 3.0 Port : 2

PCIe Expansion : 2

Redundant Power Supply

More details

Synology FlashStation FS6400
24-Bay 2.5" Rackmount NAS



Blazingly-fast all-flash server aiming for I/O-intensive applications.



Synology FlashStation FS6400 is a 2U rackmount server designed for I/O-intensive and latency-sensitive tasks, ideal for multimedia post-production, virtual machines, online transaction processing, or database applications.



Hardware Specification :

Synology FlashStation FS6400 24-Bay 2.5" Rackmount NAS

Synology NAS is shipped without hard drive & Rack Rail Kit

CPU

Intel Xeon Silver 4110 x 2 / 8-Core 2.1 (base) / 3.0 (turbo) GHz

Hardware Encryption Engine (AES-NI)

System Memory

32 GB DDR4 ECC RDIMM (16 GB x 2)

Memory Expandable up to 512GB (32 GB x 16)

Drive Bays

24 Drive Bays Hot Swappable

Maximum Drive Bays 48 with RX1217sas

Maximum Drive Bays 72 with RX2417sas

Compatible Drive Type

2.5" SATA SSD

2.5" SAS HDD

2.5" SAS SSD

(hard drives not included)

Supported RAID Type

RAID F1 / Basic / JBOD /

RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10

External Ports

RJ-45 1GbE LAN Port : 2 (with Link Aggregation / Failover support)

RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)

USB 3.0 Port : 2

Expansion Port : 1

PCIe Expansion

2 x Gen3 x8 slot (x8 link)

Maximum IP cam

128 (including 2 Free License)

Power Supply Unit  Redundant Power Supply 800W
Size 88 x 482 x 724 mm
Weight  17.26 kg
Warranty 5 year
