QNAP TS-2888X-W2123-32G 28-bay AI-Ready NAS

Display all pictures

Print
View full size

AI-Ready NAS

CPU : Intel Xeon Processor W-2123

Memory : 32GB DDR4 ECC

LAN Port : 2 x 10GBASE-T ; 4 x 1GbE

USB : 4 x USB 3.0 ; 4 x USB 3.0

PCIe : 8 x PCIe 3.0

More details

More info

QNAP TS-2888X-W2123-32G AI-Ready NAS

Built for AI. Ready for Intelligence.

Up to 18 cores with 36 threads and up to 4.5 GHz with Intel Turbo Boost Technology 2.0, combined with up to 512 GB DDR4 ECC RDIMM 2666 MHz memory to deliver rapid workload loading and processing.

The TS-2888X utilizes a hybrid architecture with high-capacity HDDs and high-performance SSDs to meet your simultaneous needs for scale and performance. It supports up to 4 graphics cards to deliver tremendous computing power for accelerating AI machine learning.

Hardware Specification :

QNAP TS-2888X-W2123-32G AI-Ready NAS

CPU	Intel Xeon W-2123 4-core 3.6 GHz Processor (burst up to 3.9 GHz)
Memory	32GB DDR4 ECC Registered RAM (4 x 8GB) expandable up to 512 GB (8 x 64GB)
Flash Memory	4GB (Dual boot OS protection)
Hard Disk Tray	8x 3.5"/2.5" SATA 6Gb/s HDD ports 16x 2.5" SATA 6Gb/s SSD ports 4x 2.5" U.2 SSD ports (PCIe 3.0 x4 per port) The system is shipped without Hard Disk
Drive Compatibility	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: U.2 slot: 2.5-inch U.2 NVMe Gen3 x4/x2 solid state drives SATA slot: 2.5-inch SATA solid state drives
LAN Port	2 x 10GBASE-T ; 4 x 1GbE
USB	6x USB 3.0 port 4x USB 2.0 port
PCIe Slot	8 x PCIe 3.0 Slot 1: PCIe Gen3 x8 or x4 (CPU) Slot 2: PCIe Gen3 x4 (CPU) Slot 3: PCIe Gen3 x8 or x4 (CPU) Slot 4: PCIe Gen3 x4 (CPU) Slot 5: PCIe Gen3 x8 or x4 (CPU) Slot 6: PCIe Gen3 x4 (CPU) Slot 7: PCIe Gen3 x4 (PCH) Slot 8: PCIe Gen3 x4 (PCH)
Audio Input	2 x 3.5mm microphone jacks (dynamic microphones only)
Audio Output	speaker, 3.5mm line out jack (for amplifier or headphone amplifier)
Power Supply	2000W single power supply
Dimensions	612 × 374 × 448
Weight	26.7 kg
