Rackmount / Redundant Power Supply
CPU : Intel Xeon D-1548, 8-core 2.0 GHz Processor
Memory : 32 GB ECC RAM (Max. 128 GB)
Harddisk Tray : 24-Bay + 6-Bay
LAN : 2x 10GbE SFP+ / 4x Gigabit
PCIe Slot : 4
USB Port : 2 x USB 3.0
Powered by an Intel Xeon D processor, the powerful enterprise-class TES-3085U is open for two operating systems – either the FreeBSD-based QES or Linux-based QTS. While QES supports ZFS for the utmost reliability and allows near-limitless snapshots, block-level data deduplication and real-time data compression, QTS features Qtier Technology, SSD cache, and an abundance of value-added apps to realize storage efficiency and diverse usage applications. The TES-3085U gives the flexibility to choose from two operating systems, enabling businesses to deploy proper operating systems on multiple TES-3085U based on their needs and goals in different stages.
Price is excluded A03-57 Rail Kit.
QNAP NAS is shipped without Hard Disk
Hardware Specification :
QNAP TES-3085U-D1548-32GR
Dual OS options 18-bay Rackmount NAS
| CPU |
Intel Xeon Processor D-1548, 8-core 2.0 GHz |
| System Memory | 32 GB DDR4 ECC RAM ( 8 GB RDIMM x 4 ) / expandable up to 128 GB ( 4 x 32 GB) |
| Flash Memory | 4 GB DOM |
| Hard Disk Drive |
Front: 2.5"x 24 Rear: 2.5" SSD slot x 6 The system is shipped without Hard Disk |
| Drive Compatibility | Front: SAS 12Gb/s, SAS 6Gb/s, SATA 6Gb/s HDD and SSD Rear: SATA 6Gb/s SSD |
| LAN Port |
2 x SFP+ 10GbE ports |
| PCIe Slot |
4 |
|
USB |
2 x USB 3.0 port (rear) For QTS OS: The USB slots support pen drives and other USB-ready devices such as printers, UPS, etc. For QES OS: The USB slots are only reserved for development and debugging. |
| LED Indicators | 10 GbE, Status, LAN, Storage expansion port status |
| Buttons |
Power button and reset button |
| Form Factor |
2U, Rackmount |
| Power Supply | Redundant Power Supply 450W x 2, 90-264VAC |
| Dimensions | 88.3 x 439 x 484.5 mm |
