QNAP ES1686dc-2123IT-64G 16-Bay Active-Active dual controller NAS

Dual active controllers

QES operating system

CPU : Intel Xeon D-2123IT

RAM : 32 GB DDR3 RDIMM

Harddisk Tray : 16-Bay

Network Port : 4 x 10GbE SFP+ ; 3 x Gigabit Ethernet

รายละเอียดเพิ่มเติม


449,100.00 ฿ ราคายังไม่รวมภาษี

QNAP ES1686dc-2123IT-64G

Active-Active Dual Controller NAS



อุปกรณ์จัดเก็บข้อมูลบนเครือข่าย (QNAP NAS)

สำหรับองค์กรขนาดใหญ่ Enterprise



มาพร้อมกับแผงควบคุมแบบคู่ Active-Active Dual Controller

Intel Xeon D-2123IT 4-core Processor

และ หน่วยความจำหลัก 32GB ต่อ controller.

จึงมั่นใจในประสิทธิภาพและเสถียรภาพ ดาวน์ไทม์ต่ำแทบจะเป็นศูนย์

ทำหน้าที่เป็น แอพพลิเคชั่นเซิร์ฟเวอร์ และ สตอเรจเซิร์ฟเวอร์ ในขณะเดียวกัน

รองรับการทำงานแบบเวอร์ชวลไลเซชั่น และสำรองข้อมูลสำคัญขององค์กร

มาพร้อมระบบปฏิบัติการ QES ที่มีพื้นฐานจาก FreeBSD และ ZFS





สินค้า QNAP ES1686dc ยังไม่มีฮาร์ดดิสก์ติดตั้งมา



Hardware Specification

QNAP ES1686dc-2123IT-64G 16-Bay Dual Controller NAS

CPU

Intel Xeon D-2123IT 4-core 2.20 GHz processor

(burst up to 3.0 GHz) per controller

System Memory

32 GB RDIMM DDR4 ECC (4x 8 GB) per controller

Maximum Memory 512 GB (8 x 64GB)

Memory Slot 8 x R-DIMM/LR-DIMM DDR4

Hard Disk Drive

16 x 3.5" hard drive

SAS 12Gb/s, backward-compatible to SAS 6Gb/s

The system is shipped without Hard Disk

Drive Compatibility

3.5-inch bays:

3.5-inch SAS/SATA hard disk drives

2.5-inch SAS/SATA hard disk drives

2.5-inch SAS/SATA solid state drives

SSD Cache

Read cache only

Copy To Flash (C2F)

1 per each controller (64GB)

LAN Port

3 x Gigabit Ports for each controller

4 x 10GbE SFP+ for each controller

PCIe Slot

Slot 1: PCIe Gen 3 x8 (CPU)

Slot 2: PCIe Gen 3 x8 (CPU)

USB

2 x USB 3.2 Gen 1 per each controller

Form Factor

3U Rackmount

Power Supply 770 W Redundant/ Hot Swap Power
Dimensions 132 x 483.05 x 630.62 mm
Weight  25.83 kg
Warranty  5 years
